Products Description
1. The operating system must support the NVME protocol, UEFI mode.
2, This card requires the motherboard to support splid pcie to support 4pcs U.2 NVMe hard drives. BIOS supports PCIe slot bifurcation. Board produced by many manufacturer can be perfectly supported, such as Super, Taian, Asus, MSI, Gigabyte and so on . Please contact the motherboard manufacturer for details. If other models are installed, you need to confirm whether the motherboard supports NVME and supports splid pcie. Simply It is said that it is supported to integrate four PCIE 3.0X4 devices into one PCIE 3.0 X16 interface, otherwise only one hard disk can be identified. Example:
Find the PCIe port Bifurcation setting in the motherboard BIOS. You can say that this motherboard can support splid pcie, can support our AN24PE16 card. Find the relative PCIe SLOT, and split the PCIe SLOT settings into X4X4X4X4. After saving the settings, shut down and plug the AN24PE16 card into the corresponding PCIe slot, and connect it with a dedicated SFF-8643 TO SFF-8639 cable U. 2 NVMe hard drive, connect to the power cord. This will identify the connected NVMe hard disk under UEFI and system.
We also have 1 port Nvme U.2 SSD to PCIe X16 riser card and needn't cable:
