CEACENT CNS42PE16 is a dual port SFF8654X8 NVME hard drive adapter card independently developed by Shenzhen Xi Microelectronics Co., Ltd. It adopts the Pci-e 3.0 * 16 bus type and is compatible with PCIE4.0 bus speed. It does not require power to NVMe SSDs and supports NVMe hard drives that comply with standard protocols such as Intel. It requires the motherboard to support splitting function. Through SFF8654X8-2 * (8639X4), it can support up to 4 NVMeU2 hard drives or extend PCIE slots through ALEO series products. It can also be applied to Jiahua Zhongli NVME server chassis through SFF8654X8-SFF8654X8. The design of this hard drive adapter card is mainly used for server solution expansion and bottlenecks in high-end desktop computer storage.
CNS42PE16 is suitable for system platforms such as graphics workstations, storage servers, communication, and other storage systems. Each NVME SSD channel has a dedicated PCIe 3.0 x4 (32Gb/s) bandwidth, with transmission performance 10 times faster than SATA. Improved the speed of NVMe reuse, meeting the growing response time requirements in enterprise storage systems, and supporting the growing demand for data storage in today's enterprise applications, providing fast, reliable, and durable performance for any demanding application, making your storage solutions more convenient and efficient. It is also suitable for storage and other application environments such as ALEO dedicated servers, multi graphics card solutions, and PCIE expansion.
Instructions for using CEACNET CNS42PE16:
1. The operating system must support the NVMe protocol in order for UEFI mode to support boot.
2. This card requires the motherboard to support split split PCIe into two X8 threads in order to recognize four U2 NVME hard drives, and the BIOS supports PCLs slot bifurcation.
3. This card can use the ALEO series PCIE adapter card to expand the PCIE slot solution and is compatible with most machines in the ALEO project.
4 Two SFF8654X8 threads have a PCIEX8 thread rate;
5 The port supports PCIE4.0;
6. It can be paired with an ALEO card to expand the PCIEX8 slot through the SFF8654X8 interface, or to expand the PCIEX16 slot through 2 * 8654X8.
Many existing server motherboards from manufacturers such as AMD, Taian, Asus, MSI, and Gigabyte can support it; Please contact the customer service of the motherboard manufacturer for specific inquiries. If you need to install a different model of computer, you need to confirm whether the motherboard supports NVME and split PCIe (PCIE splitting). In simple terms, it is necessary to ensure that two PCIEs 3.0 * 8 are integrated into one PCIE 3.0 * 16 interface for use. Otherwise, there may be a situation where only one hard drive can be recognized.
For more product information, please contact our online customer service.
