CEACENT ANSL4PE16 is a NVMe U.2 (sff8639) to PCI-e 3.0 * 16, SAS 4.0 hard drive adapter card independently developed by Shenzhen Xi Microelectronics Co., Ltd. It does not require power to NVMe SSD and BIOS supports PCLs slot bifurcation. The design of this hard drive adapter card is mainly used to address storage bottlenecks in servers and high-end desktop computers. It adopts the Microchip PMC8533 chip solution, which comes with a PCIe splitting protocol and can be easily expanded without the need for motherboard support for splitting; Supports hot swapping function, making it more convenient and concise to manage your workstation; Supports up to 8 NVME HDD (SSD) extensions and supports NVMe hard drives that comply with standard protocols such as Intel.
ANSL4PE16 is suitable for storage and other system platforms such as graphics workstations, servers, and communication. The four ports can expand up to 8 U2 (sff8639 hard drives) through a 2 * 8639 SlimSAS interface. Each U2 SSD channel has a dedicated PCIe 3.0 x4 (32Gb/s) bandwidth, and the transmission performance is 20 times faster than SATA; Supports SAS4.0 interface, with a maximum transmission speed of 2400Mbyte/s; Improved the speed of NVMe reuse, making your storage solution more convenient and efficient.
Instructions for using CEACENT ANSL4PE16:
1 PCIe 3.0 x16 total bandwidth;
2 Supports hot swapping function;
3. Four ports are extended with 8 U2 NVMe channels (providing dedicated PCIe 3.0 X4 bandwidth for each port) through SlimSAS-2 * 8639;
4 The port supports SAS4.0 interface, with a maximum transmission speed of 2400Mbyte/s;
5. BIOS supports PCLs slot bifurcation
6. Adopting Microchip's PMC8533 control scheme;
7 provides high-performance storage solutions for NVMe SSDs.
There are no operating system or motherboard model compatibility requirements, and simply having a PCIe slot on the motherboard allows for easy expansion.
For more product information, please contact our online customer service.
