This is a 4x 53.125Gbps multi mode fiber, hot pluggable optical transceiver.The module integrates four parallel lanes with baud rate at 26.5625GBd each lane. It can transmit up to 70m on fiber OM3 fiber or 100m on OM4 fiber with FEC.
PRODUCT FEATURES：
Compliant with 200G-SR4 optical specifications
4x53.125Gb/s electrical interface (200GAUI-4)
Reach up to 70m on MMF(OM3)
Reach up to 100m on MMF(OM4)
Single +3.3V power supply
Case temperature range: 0 ~ +70℃
Maximum power consumption 4W
Single MPO12 connector
RoHS complaint
APPLICATIONS：
200G BASE-SR4 Ethernet links
Data centers
Standards：
IEEE 802.3cd
SFF 8679
CMIS4.0 or SFF8636
