CEACENT CS3808-8E is a PCI Express 4.0 * 8 eight port NVMe HBA hard drive expansion card independently developed by CEACENT based on the LSI SAS3808 main control scheme. The adapter automatically negotiates backward compatibility with previous SAS and PCI-E versions
This HBA expansion card comes with two SFF8644 * 2 channel types and supports up to 8 12Gb/S SAS/SATA ports; The product serves four main target markets: wireless communication, wired infrastructure, enterprise storage, and industrial and other.
CEACENT has extensive experience in storage solutions and over 20 years of independent research and development projects. It is a well-known benchmark enterprise in the field of server boards in the industry.
key characteristics
• Three mode storage interface − 12Gb/s SAS − 6Gb/s SATA − Gen 4.0 PCIe (NVMe) • Hardware safe boot
• Universal Management (UBM) Ready (SFF-TA-1005) • 13700 MBs (256K Seq Rd) • 3M IOPs (4K RR) • x8 PCIe Gen 4.0 Host Interface - Supports x8, x4, x2, x1 PCIe channels with a transfer rate of up to 16.0 GT/s per channel, full duplex - channels with polarity reversal
Connector pin output compliant with SFF-9402
Up to 1024 SAS/SATA devices
Up to 32 NVMe devices
• Cable export with a friendly appearance
