The CEACENT CC35X12-12S storage server backplane is a customized product launched by Xi Microelectronics Co., Ltd. for adapting to the series -2U 12 bay storage servers. The backplane adopts a mature LSI 35X Expander master control scheme, equipped with 3 large PIN power supply ports, 2 SFF8643 data access ports, and can connect up to 12 SAS/SATA disks, with a 12Gb/S transmission rate and fast transmission, leading the Aoling forward; Equipped with a cascaded interface on the front, it can easily expand more storage slots and flexibly configure application solutions; Embedded MAX-V management chip, CPLD signal code, can monitor the working status of the hard disk in real-time through the chip, and provide timely feedback through LED status indicators, with high compatibility and stability. CC35X12-12S provides advanced management functions and storage technology, with reliable scalability and high availability.
CC35X12-12S is made of TG170 high-temperature resistant board, 8-11 layers of PCB laminated design, and high-density technology; Independent chip cooling layer, magnetic circuit shielding layer, high-speed circuit, ensuring signal integrity; With its efficient design, while ensuring excellent design; It also takes into account flexible and powerful resource expansion capabilities, high temperature resistance, strong heat dissipation, high impedance, and excellent reliability. It is often used for business applications of small databases, enterprise informatization, online games, WEB search, file services, VOD, Mail, virtualization, medium-sized databases, enterprise informatization, IDC/ISP/ICP/ASP, and other network and information operators.
Instructions for using CEACENT CC35X12-12S:
1. Supports 12 SAS/SATA (SFF8482) Expander extensions
2. Broadcom (Lsi) SAS master control scheme with 12G/S transmission rate.
3. Three large PIN power supply ports
4. Provide two data access ports and a cascading interface for easy expansion.
5. Reserve two COM debugging interfaces.
Ximicroelectronics can be applied to multiple chassis factories according to customer needs, with physical structure dimensions of 2U/12 4U/24 4U/36. Please consult the customer first when placing an order. For more product information, please contact online customer service.
