The CEACENT CC3K12-12S storage server straight through backplane is a customized product launched by Xi Microelectronics Technology Co., Ltd. for adapting to the series -4U 24 bay storage servers. The backplane is equipped with three large 4PIN power supply ports and three SFF8643 data access ports. The SAS/SATA expansion scheme can be selecte according to customer needs, allowing for easy expansion of more storage slots and flexible configuration; Up to 12 SAS/SATA hard drives can be connected, with a 12Gb/S transmission rate and fast transmission, leading the way forward; Embedded UBM management chip, GPLD signal code, can monitor the working status of the hard disk in real-time through the chip, and provide timely feedback through the LED status indicator light, with strong compatibility and high stability!
CC3K12-12S provides advanced management functions and storage technology, with reliable scalability and high availability! The product is made of TG170 high-temperature resistant board, 8-layer PCB laminated design, and high-density technology; Independent chip cooling layer, magnetic circuit shielding layer, high-speed circuit, ensuring signal integrity; With its efficient design, while ensuring excellent design; It also takes into account flexible and powerful resource expansion capabilities, high temperature resistance, strong heat dissipation, high impedance, and excellent reliability. It is often used for business applications of small databases, enterprise informatization, online games, WEB search, file services, VOD, Mail, virtualization, medium-sized databases, enterprise informatization, IDC/ISP/ICP/ASP, and other network and information operators.
Instructions for using CEACENT CC3K12-12S:
1. Supports 12 SAS/SATA hard disk expanders
2. Direct connected Expander scheme with 12Gb/S transmission rate
3. Three large 4PIN power supply ports
4. Provide 3 SFF8643 data access ports for easy expansion and flexible configuration
Ximicroelectronics can be applied to multiple domestic chassis factories according to customer needs, with physical structure dimensions of 2U/12 4U/24 4U/36. Please consult the customer first when placing an order. For more product information, please contact online customer service.
