The MegaRAID 9480-8i8e three mode internal / external storage adapter is a 12Gb/s SAS/SATA/PCIe (NVMe) controller card that meets these requirements by providing internal connectivity and external scalability, verified flexibility, performance and RAID data protection for a series of server storage applications.

　　1. Broadcom's three mode SerDes technology enables NVMe, SAS or SATA devices to run in a single drive bracket, thus achieving unlimited design flexibility.

　　2. Each controller can connect up to 240 SAS / SATA devices or 24 nvme devices

　　3. Suitable for rack server with light profile and side mounted SAS connector

　　4. Provide internal storage, external JBOD expansion and raid data protection to meet various storage performance and capacity requirements

　　5. Support for high bandwidth PCIe applications 1.3

　　6. Use RAID levels 0, 1, 5, 6, 10, 50, and 60 to balance protection and performance for critical applications

　　7. Add more protection and peace of mind with cachevault? Flash protection
