CEACENT CF40GSLQF1 Transceiver is designed for 10km optical communication applications. This module contains 4-lane optical transmitter, 4-lane optical receiver and module management block including 2 wire serial inter-face. The optical signals are multiplexed to a single-mode fiber through an industry standard LC connector
PRODUCT FEATURES：
Support line rates for 41.25 Gb/s
Lane bit rate 10.3125 Gb/s
CWDM DML laser and PIN ROSA
Up to 10km transmission on SMF
Support Multi-Pin function with IntL/RxLOSL and LPMode/TxDIS
I2C interface with integrated Digital Diagnostic monitoring
Digital Diagnostics Monitoring Interface
Compliant with QSFP+ MSA with LC connector
Single +3.3V power supply
Power dissipation: Commercial：< 3.5W Industrial：<4.5W
Complies with EU Directive 2015/863/EU
APPLICATIONS：
40G Ethernet
InfiniBand QDR, DDR and SDR
