It is a Four-Channel, Pluggable, Fiber-Optic CF40GSQF1 for 40Gigabit Ethernet and Infiniband EDR applications. This transceiver is a high performance module for data communication and interconnect applications. It integrates four data lanes in each direction with 40Gbps bandwidth. The length of QSFP+ SR4 is up to 100 meters over OM3 MMF or 150 meters over OM4 MMF. This module is designed to operate over multimode fiber systems using a nominal wavelength of 850nm. It contains a MPO connector for the optical interface and a 38-pin connector for the electrical interface.
PRODUCT FEATURES：
High quality and reliability optical device and Sub-assemblies
4 VCSEL Lasers and 4 channels PIN photo detectors
Maximum link length of 100m on OM3 MMF or 150m on OM4 MMF
Compliant with SFF-8436 for electrical interface
Compliant with SFF-8436 for mechanical interface
QSFP+ Mechanical Interface for easy removal
MPO Receptacle
Compliant with SFF-8436 for 2-wire interface for management and DDM
IEEE Std802.3ba
SFF-8436
Less than 1.5W in temperature range of 0 to 70℃
APPLICATIONS：
40G SR4 Ethernet links
Data center
Other high speed data connections
