CEACENT CF10GSLF1 Transceiver is designed for 10GBASE-LR/LW and 8.5G/10G Fiber- Channel applications. The transceiver consists of two sections: The transmitter section incorporates a DML laser. And the receiver section consists of a PIN photodiode integrated with a TIA. All modules satisfy class I laser safety requirements. Digital diagnostics functions are available via a 2-wire serial interface, as specified in SFF- 8472, which allows real-time access to device operating parameters such as transceiver temperature, laser bias current, transmitted optical power, received optical power and transceiver supply voltage.
PRODUCT FEATURES：
Electrical interface specifications per SFF-8431
Management interface specifications per
SFF-8431 and SFF-8472
SFP+ MSA package with duplex LC connector
1310 DFB Transmitter
Up to 11.3Gb/s data links
Single +3.3V power supply
Class 1 laser safety certified
Up to 10km on 9/125µm SMF
Operating Case Temperature: C-Temp:0 ~ +70℃. I-Temp:-40 ~ +85℃
RoHS Compliant
APPLICATIONS：
10GBASE-LR/LW
10G Fiber Channel
Wireless
