| Lifecycle |
Active |
| Distrib. Inventory |
No |
| RAID-on-Chip Controller |
|
| What's in the box |
|
| Generation |
|
| External Connectors |
|
| RAID Management Software |
|
| Management Software |
LSI Storage Authority (LSA), StorCLI (Command-Line Interface), HII (UEFI Human Interface Infrastructure) |
| Cache Protection |
CacheVault CVPM05 |
| Physical Dimensions |
Low profile 6.127” x 2.712” |
| Host Bus Type |
x8 lane PCI Express® 3.1 |
| Cache Memory |
4GB 2133 MHz DDR4 SDRAM |
| Internal Ports |
16 |
| Data Transfer Rates |
|
| Devices Supported |
SAS/SATA: 240, NVMe: 24 |
| Internal Connectors |
4 Mini-SAS HD x4 SFF-8643 |
| MTBF |
|
| Operating Temperature |
0°C to 55°C |
| Operating Voltage (V) |
+12V +/-8%, 3.3V +/-9% |
| OS |
Microsoft Windows. Contact Oracle support for Oracle Solaris driver or software support. See www.broadcom.com/support/down-load-serach for details on versions. |
| Regulatory Certifications |
Australia/New Zealand (AS/NZS CISPR 22), Canada (ICES -003, Class B), Europe (EN55022/EN55024), Japan (VCCI V-3), Korea (RRA no 2013-24 & 25), RoHS compliant, Safety: EN/IEC/UL 60950, Taiwan (CNS 13438), USA (FCC 47 CFR part 15 Subpart B, class B), WEEE |
| Warranty |
3 years, free technical support, advanced replacement option at broadcom.com/support/warranty/internal-raid-hba |
| I/O Processor / SAS Controller |
SAS3516 dual-core RAID-on-Chip (ROC) |
